Genuine Tohatsu Thermostat BFT60 BFT75 BFT90 HZW9-19300-003
HZW9-19300-003
- Dispatched in 2-3 days
- 30 Day Return Policy
- Low stock - 4 items left
- Backordered, shipping soon
Genuine Tohatsu 60°C Thermostat for BFT Outboards
Genuine Tohatsu thermostat assembly for selected Honda-based BFT four-stroke outboards. It regulates coolant flow as the engine warms, helping the powerhead reach and maintain its designed operating temperature.
Verified Tohatsu Compatibility
- BFT60A: 60 HP four-stroke — selected models including 2018–2019 catalogues
- BFTW60A Power Thrust: 60 HP four-stroke — selected models including 2018–2019 catalogues
- BFT75AK1: 75 HP four-stroke — selected models including 2018–2019 catalogues
- BFT90AK1: 90 HP four-stroke — selected models including 2018–2019 catalogues
Not for MFS15A–MFS30A: the previous small-engine compatibility was incorrect. Confirm the BFT model code and serial number before ordering.
Technical Specifications
| Part type | Engine cooling thermostat assembly |
| Nominal opening temperature | 60°C / 140°F |
| Tohatsu OEM reference | HZW9-19300-003 |
| Honda OEM cross-reference | 19300-ZW9-003 |
| Engine type | BFT four-stroke outboard |
| Quantity supplied | One thermostat assembly |
Seal not included: the thermostat-cover O-ring is catalogued separately as HZW9-19317-000. Inspect it during service and replace it when required.
Check Before Ordering & Installation
- Read the complete BFT model code and serial number from the outboard identification plate.
- Confirm HZW9-19300-003 in the exact engine parts diagram.
- Check the thermostat-cover O-ring and order it separately if needed.
- Install only on a cold engine, following the factory service procedure and torque values.
Cooling-system faults can have several causes. A blocked water intake, damaged impeller or restricted passage should also be checked if the engine overheats or runs too cold.
Frequently Asked Questions
Does this fit a Tohatsu MFS20 or MFS30?
No. The former MFS15A–MFS30A compatibility was incorrect; this thermostat is for the listed BFT families.
Is the thermostat-cover O-ring included?
No. The O-ring is a separate service item and should be inspected or replaced during installation.
What temperature is the thermostat rated for?
The nominal opening specification is 60°C / 140°F.
Can I identify fitment by horsepower alone?
No. Use the full BFT model code, suffix, year and serial number because different engine families at similar horsepower can use different cooling parts.
