SEAFLO 24V Electric Marine Toilet Flush and Macerator Pump Assembly
MTP201
- Dispatched in 2-3 days
- 30 Day Return Policy
- In stock, ready to ship
- Backordered, shipping soon
SEAFLO 24V Electric Marine Toilet Flush and Macerator Pump Assembly
Replacement pump assembly for a SEAFLO electric marine toilet
A 24V dual-function toilet pump assembly that self-primes rinse water into the bowl while the macerator and scavenger section grinds and evacuates waste. It is intended for service or replacement within a compatible SEAFLO electric marine toilet installation.
Key Features
- ✔ For SEAFLO 24V electric toilet systems using the matching SFMTE2-01 pump arrangement.
- ✔ Do not assume compatibility with Jabsco or another brand from appearance alone; no cross-brand direct-fit claim is made.
- ✔ Compare original pump label, voltage, mounting holes, shaft/orientation, inlet, discharge, switch wiring and available space.
- ✔ Marine sanitation systems require correct seacocks and vented loops when installed at or below the waterline.
Technical Specifications
| Compatible SEAFLO family | SFMTE2-01 / SFMTE2-01-R 24V systems |
| Supply voltage | 24V DC |
| Maximum current draw | 10A |
| Functions | Flexible-impeller rinse pump plus macerator/scavenger discharge |
| Control | External switch-panel operation |
| Water inlet | 3/4in |
| Waste discharge | 1in, with 1in to 1-1/2in adapter used in the toilet configuration |
| Motor | Fully enclosed permanent-magnet motor with stainless-steel shaft |
| Protection/features | Built-in backflow preventer and corrosion-resistant marine materials |
Installation and package contents
- This is a sanitation and high-current electrical repair; isolate power and close seacocks before work.
- Use sanitation-rated hose, secure clamps and correctly sized 24V wiring and circuit protection for the 10A maximum draw.
- After installation, test rinse, maceration, discharge and leak integrity before returning the toilet to service.
- Listing is for one replacement flush/macerator pump assembly, not a complete ceramic toilet. Confirm whether switch, adapter, seals and fasteners are present in the supplied pack.
Questions & Answers
Is a complete marine toilet included?
No. This is the replacement 24V pump assembly only.
Will it replace any 24V toilet pump?
No. Match the original SEAFLO family, mounting, ports and wiring before ordering.
Can it run on 12V?
No. This version is designed for 24V DC.
Does it both rinse and discharge?
Yes. The assembly combines a rinse-water pump with a macerator/scavenger discharge function.
Note: Please verify voltage, capacity and fitting sizes against your boat before ordering. For technical support, contact us via 4boats.co.uk.
