Seaflo Heavy Duty Float Switch BS2505

Name: Seaflo BS2505 Heavy Duty 25A Electromagnetic Bilge Pump Float Switch 12V 24V 32V
Brand: SEAFLO
Price: 49.99 GBP
Rating: 5 (1 reviews)

Premium 25A Electromagnetic Control for High-Flow Pumps

The Seaflo BS2505 (05-Series) represents the pinnacle of bilge water management technology. Unlike traditional mechanical switches that often fail due to debris or seal leakage, this heavy-duty unit utilizes electromagnetic activation. By using magnetic force to trigger the pump, the internal mechanism remains completely enclosed and protected from the harsh bilge environment.

ENGINEERED FOR POWER: Specifically designed to handle the high current demands of manual bilge pumps with flow rates exceeding 3000 GPH.

Key Features

✔ Electromagnetic Design: No mechanical seal to leak or fail.
✔ Debris Protection: Enclosed housing prevents clogs.
✔ High Capacity: Rated for a massive 25 Amps.
✔ Mercury-Free: Environmentally friendly and safe.
✔ Quick Installation: Includes detachable base for easy cleaning.

Technical Specs

Model:	BS2505 / SFBS-25-05
Voltage:	12V / 24V / 32V DC
Max Amps:	25A (12V) / 12.5A (24V)
Wire Gauge:	14 AWG (1m length)
Turn ON Level:	45mm - 50mm (1.77" - 1.97")
Turn OFF Level:	20mm - 25mm (0.79" - 0.98")

Compatibility / Fitment Guide

System Application	Compatible Flow Rates	Notes
Marine Bilge Systems	3000 GPH, 3500 GPH, 3700 GPH+	Best for high-amp non-auto pumps.
12V/24V/32V DC Power	Universal Replacement	Must use correct fuse size for pump.

OEM Cross Reference

Manufacturer	Reference Number
Seaflo (Standard)	SFBS-25-05
Seaflo (UK/EU)	BS2505
EAN Barcode	6971170931897

Questions & Answers

Is this a genuine Seaflo part?

Yes, this is an authentic Seaflo 05-Series heavy-duty electromagnetic float switch, supplied in original packaging.

Why do I need a 25A switch instead of a standard 15A or 20A?

High-flow bilge pumps (3000GPH and above) have a significantly higher amp draw upon startup. A standard switch may burn out or fuse closed under these loads; the BS2505 is built specifically to handle that surge safely.

Can this be used in salt water?

Yes. The ABS thermoplastic construction and marine-grade tinned wiring are designed specifically for both fresh and salt water environments.

Note: Ensure the switch is mounted horizontally (max 30° tilt) for optimal electromagnetic float performance. Available via 4boats.co.uk.
