SEAFLO 12V 800GPH Automatic Bilge Pump 14A Series BP1G80014A Water Level Sensing
BP1G80014A
- Dispatched in 2-3 days
- 30 Day Return Policy
- In stock, ready to ship
- Backordered, shipping soon
SEAFLO BP1G80014A 800GPH PUMP
14A Series Low Profile Automatic Water Level Sensing
The SEAFLO 14A Series represents the pinnacle of narrow-profile bilge technology. Specifically designed for tight or awkwardly shaped bilge spaces, this 800 GPH pump features an integrated water level sensor that eliminates the need for a separate float switch. Its unique 360-degree rotating discharge allows for effortless installation in any orientation, ensuring your vessel remains dry even in the most restricted areas.
Key Features
- ✔ Auto-Sensing: Internal sensor starts at 4.5cm water level
- ✔ Low Profile: Ideal for narrow/shallow bilges
- ✔ 360° Rotation: Pump body rotates to fit plumbing
- ✔ Check Valve: Integrated non-return valve included
- ✔ Ignition Protected: Safe for all marine engine rooms
Technical Specs
| Flow Rate: | 800 GPH (3028 LPH) |
| Voltage: | 12V DC |
| Current Draw: | 3.2 Amps |
| Fuse Size: | 6.0 Amps |
| Max Head (Lift): | 3.2m (10.5') |
| Outlets Included: | 19/25/29mm Barbs |
| Wire Lead: | 1m (18 AWG) |
Compatibility / Fitment Guide
| Make/System | Model/Application | Notes |
|---|---|---|
| Marine Vessels | Boats up to 24m (79ft) | Primary Bilge Pump |
| Low Clearance Bilge | Kayaks, Bass Boats, Cruisers | Narrow Profile Application |
| 12V DC Systems | Universal Replacement | Standard Marine Wiring |
OEM Cross Reference
| SEAFLO SKU | BP1G80014A |
| Alternative SKU | SFBP1-G800-14A |
| Series Group | 14A Series (Automatic) |
Questions & Answers
Is this a genuine original part?
Yes, this is a genuine SEAFLO 14A Series automatic bilge pump, manufactured to exceed marine standards and ISO 8846/8849 certifications.
How do I know if it is compatible?
We recommend checking the SKU BP1G80014A. If your existing pump is a standard 12V 3/4" outlet pump, this will fit perfectly, especially in narrow bilge areas where vertical space is limited.
Does this pump require a separate float switch?
No, the 14A series features a built-in water level sensor. It automatically turns on when the water reaches approximately 4.5cm (1.77") and shuts off when the level drops below 1cm (0.39").
Note: Please verify your original part number and bilge dimensions against the specifications above before purchasing. Part of the 4boats.co.uk marine equipment range.
