Waveline Outboard Engine Bracket Stainless Steel Wood Pad 25HP 60kg Max WL-1005
WL-1005
- Dispatched in 2-3 days
- 30 Day Return Policy
- In stock, ready to ship
- Backordered, shipping soon
Waveline Outboard Bracket WL-1005
Stainless Steel | 25HP Max | 60kg Load Capacity
The Waveline WL-1005 is a premium, heavy-duty adjustable outboard bracket designed for mounting auxiliary engines and trolling motors to boat transoms. Constructed from high-grade marine stainless steel, this bracket provides the strength and corrosion resistance required for harsh saltwater environments.
Key Features
- ✔ Heavy-duty spring-assisted lift mechanism
- ✔ Marine-grade stainless steel frame
- ✔ Substantial varnished wood mounting pad
- ✔ Multiple height adjustment positions
- ✔ Rigid mounting for reduced vibration
Technical Specs
| Max Motor Power | 25 HP |
| Max Weight Load | 60 kg (132 lbs) |
| Material | Stainless Steel |
| Pad Type | Marine Wood |
| Mount Holes | approx. 8.5mm |
| Adjustment | 4-Position Height |
Compatibility / Fitment Guide
| Engine Type | Application | Notes |
|---|---|---|
| 4-Stroke Auxiliaries | Up to 25HP | Specially rated for higher 4-stroke weight. |
| 2-Stroke Outboards | Up to 25HP | Universal fit for standard 2-stroke clamps. |
| Transom Type | Flat Vertical/Angled | Fits most sailboats and powerboat transoms. |
OEM Cross Reference
| Brand / Distributor | Part Number |
| Waveline | WL-1005 / MA WL-1005 |
| Sowester | SOW6105 |
| Trem (Equiv) | 67002/1 |
Questions & Answers
Is this a genuine original part?
This is a premium quality Waveline aftermarket part, engineered to meet or exceed marine-grade safety standards for high-capacity auxiliary mounting.
How do I know if it is compatible?
Check your engine's dry weight. This bracket is rated for up to 60kg. If your motor (common for 10HP-25HP 4-strokes) falls under this limit, it is compatible. The mounting pattern is a standard universal 4-bolt transom design.
Is this bracket suitable for a 4-stroke engine?
Yes, the 60kg capacity is specifically designed to accommodate the heavier weight and higher torque of modern 4-stroke outboard engines compared to standard lightweight brackets.
Note: Mounting bolts are not included as required length depends on transom thickness. Please verify your original part number against the references above before purchasing. Visit 4boats.co.uk for further assistance.
