Multiflex 13ft Mechanical Steering Kit Up to 150HP Outboard Boat SC-16-13KIT
SC-16-13KIT
- Dispatched in 2-3 days
- 30 Day Return Policy
- In stock, ready to ship
- Backordered, shipping soon
Multiflex Steering Kit SC-16-13KIT
Complete 13ft Mechanical Rotary System for Engines up to 150HP
The Multiflex SC-16-13KIT is a comprehensive mechanical steering solution designed for boats powered by outboard engines up to 150HP. Featuring a high-efficiency planetary geared helm, this kit provides smooth and responsive control, significantly reducing the effort required at the wheel compared to standard reduction gear systems.
What's in the Box
- β Steering Helm (LM-H-101): Easy Connect Rotary Helm
- β Steering Cable (SC-16-13): 13ft (3.96m) Length
- β Bezel Kit (LM-B-1): 90 Degree Black Plastic Bezel
- β Hardware: All necessary mounting fasteners
Technical Specs
| Max Horsepower | 150 HP |
| Cable Length | 13 Feet (3.96m) |
| Turns Lock-to-Lock | ~3.8 Turns |
| Max Wheel Dia. | 16" (400mm) |
| Shaft Type | Standard 3/4" Tapered |
| Stroke Length | 9" (228mm) |
Compatibility / Fitment Guide
| System Type | Compatibility Note | Engine Application |
|---|---|---|
| Outboards | Direct Tilt Tube Mounting | Up to 150HP |
| Sterndrives | Fits standard power-assisted systems | Standard Marine Sterndrives |
| Mounting | Requires standard helm cutout | Fits most console dashes |
OEM Cross Reference
| Brand | Equivalent Part Number |
|---|---|
| Teleflex / SeaStar | SSC62 / SSC92 / Safe-T QC |
| Ultraflex | M-66 / T71FC / T72FC / T85 |
| Morse | 291008 / 304411 (Compatible Cable Series) |
Questions & Answers
Is this a genuine original part?
This is a premium Multiflex steering kit, which is a leading global brand in mechanical steering systems. It is designed to be fully interchangeable with Teleflex and Ultraflex systems.
How do I know if it is compatible?
Check your existing cable jacket for a stamped part number. If it says SSC62, M-66, or SC-16, this kit is the correct replacement. Ensure your engine is rated at 150HP or less.
What does "Easy Connect" mean?
The Easy Connect system allows the steering cable to be attached to the helm without the need for specialized tools, using a simple locking pin mechanism that reduces installation time.
Note: Please verify your required cable length before ordering. Steering cables are measured from the plastic tip of the helm end to the center of the output hole on the engine end. For technical support, please contact us at 4boats.co.uk.
