Johnson Evinrude Outboard Zinc Anode 5035786 | Replaces 18-6032 | 30HP 4-Stroke
55320-95311JE
- Dispatched in 2-3 days
- 30 Day Return Policy
- Low stock - 2 items left
- Backordered, shipping soon
Suzuki Johnson Evinrude Zinc Anode 55320-95311 5035786 18-6032
SKU / MPN: 55320-95311JE
Small internal sacrificial zinc anode for specific Suzuki outboard cooling-block locations and corresponding Suzuki-built Johnson/Evinrude four-strokes. Model, year and the anode position in the parts fiche must agree; the same engine can use several different anodes.
Technical specification
| Key fitment / installation | Exact anode position and OEM number are mandatory: selected Suzuki DF25-DF300 applications and Suzuki-built Johnson/Evinrude 25-225HP four-strokes. Use only where the parts fiche specifies 55320-95310/95311, 5030265 or 5035786 for this 40 x 30 x 12mm internal anode. |
| Brand | Aftermarket |
| SKU / MPN | 55320-95311JE |
| Part supplied | 1 zinc anode |
| Material | Zinc for salt-water service |
| Reference size | 40 x 30 x 12mm |
| Centre recess | Approx. 17mm |
| Mounting hole | Approx. 6.5mm |
| Weight | Approx. 80g |
Compatibility / suitable applications
- Suzuki DF25 / DF30: selected 2000-2007 models
- Suzuki DF40 / DF50: selected 1999-2008 models
- Suzuki DF40A / DF50A / DF60A: selected 2010-and-later applications where 55320-95311 is shown in the parts fiche
- Suzuki DF60 / DF70: selected 2001-2008 models
- Suzuki DF150 / DF175: selected 2006-and-later applications
- Suzuki DF200 / DF225 / DF250: selected 2004-and-later applications
- Suzuki DF300: selected 2007-and-later applications
- Selected Suzuki DT two-strokes only where the parts fiche specifies 55320-95310/95311
- Suzuki-built Johnson/Evinrude four-strokes, including selected 25-225HP 2004-2007 applications, only where OEM 5030265 or 5035786 is specified
Part-number references
- Suzuki 55320-95310, 55320-95311, 55321-93J00, 55321-93J01
- Johnson/Evinrude 0769633, 5030265, 5035786
- Sierra 18-6032; Tecnoseal 01204
- Not a trim-tab or external bracket anode
- Zinc is for salt water; do not choose it automatically for fresh-water use
- Do not paint the anode
- Check the parts fiche for exact position and quantity; horsepower alone is insufficient
- Mounting bolt is not stated as included
Frequently asked questions
Can I choose this anode from horsepower alone?
No. One engine can use several different anodes. Confirm the exact anode position in the parts fiche, the model/year, the original part number and the 40 x 30 x 12mm dimensions before ordering.
What is included in this product?
1 zinc anode. No additional parts are included unless they are explicitly listed in the technical specification.
How do I confirm compatibility?
Match the exact model or installation type, all stated technical specifications and at least one listed OEM/manufacturer reference. Horsepower, appearance or overall size alone is not enough.
Is this a genuine OEM part?
No. This is a new aftermarket replacement part; the OEM names and numbers are used only to identify compatibility.
What should I send if I am unsure?
Send the complete engine or equipment model, serial number, the number on the original part and clear photos of the connections and mounting points before ordering.
Before ordering
- Find the engine model and serial number, or measure the installation—not just the old item's appearance.
- Confirm the original OEM number and all electrical/mechanical specifications.
- If unsure, send us the model, serial number and clear photos before purchase.
