Victron SmartSolar MPPT 100/20 20A solar charge controller | 4Boats

Compact 20 A MPPT solar charge controller with built‑in Bluetooth and Victron BatteryLife for reliable battery protection and maximum energy harvest.

• Ultrafast MPPT Technology: This 20 A MPPT solar charge controller is designed to deliver the highest possible energy yield using high‑speed Maximum Power Point Tracking for superior performance, including excellent low‑light results.
• Inbuilt safety protection: Fully equipped with an extensive range of safety features, including battery reverse polarity protection, load short‑circuit protection, low‑voltage load disconnect and battery overheating monitoring via an internal temperature sensor; self‑diagnostic fault reporting via high‑intensity LEDs.
• Intelligent BatteryLife function: To prevent complete discharge and avoid potentially permanent damage, the BatteryLife algorithm monitors state of charge and limits excessive loads to extend battery lifetime.
• Inbuilt Bluetooth and live data: This SmartSolar charge controller features built‑in Bluetooth allowing monitoring with VictronConnect. Live data transmission provides real‑time solar panel voltage, current and power; data logs store system activity for the past 30 days and include total energy counters.
• Load configuration and remote options: Choose from pre‑set load management programmes or create a custom profile. Optional MPPT control panel (sold separately) and VE.Direct/USB connectivity are supported for local display and configuration.
• Specifications: Max solar panel voltage: 100 V. Max solar panel power: 290 W (12 V) / 580 W (24 V) / 1160 W (48 V). Charge/load current: 20 A (12/24/48 V). Efficiency >95%. Self‑consumption (load off): 12 V: 10 mA / 24 V: 8 mA / 48 V: 7 mA. Self‑consumption (load on): 12 V: 26 mA / 48 V: 19 mA. Working temperature: -30°C to +60°C (-22°F to +140°F).
• Communications & certifications: RS232 / TTL for VE.Direct accessories; IEC/EN certified; Pollution Degree rating PD3.
• Mechanical & installation: Enclosure IP43 (electronic components) / IP22 (connection area). Dimensions: 100 x 113 x 60 mm (3.94 x 4.45 x 2.36 in). Mounting dimensions: 99 x 84 mm. Weight: 650 g (1.43 lb). 4 x mounting holes for ease of installation. User manual and supporting documents available to download.

Compatible with 12 V, 24 V and 48 V battery systems. Configure and monitor using the VictronConnect app or VE.Direct accessories; optional remote display sold separately.
