VICTRON 25A 12V BLUE SMART IP65 MAINS BATTERY CHARGER WITH BLUETOOTH CONNECTIVITY

The VICTRON 25A 12V BLUE SMART IP65 MAINS BATTERY CHARGER offers effective and reliable charging with 25A output and Bluetooth connectivity. With an IP65 rating and steady current, it is designed for optimal battery health, performance and longevity. It is easy to use and provides exceptional efficiency and power.

This?ÿVictron 25A 12V?ÿBlue Smart IP65 mains battery?ÿcharger?ÿis designed to enable safe and efficient unattended charging of a 12V battery or battery bank from a mains power source (220-240V AC). This mains charger boasts an outstanding?ÿ94%?ÿefficiency, along with an adaptive automatic 7-stage charging process?ÿto deliver faster and more efficient charging. This unit also uniquely features?ÿBluetooth connectivity, which enables the user to remotely monitor the charging system on a mobile device.

This unit?ÿis able?ÿto charge either a single 12V battery, or several 12V batteries connected in parallel (batteries must be the same?ÿtype, capacity and age).

This mains battery charger is compatible with?ÿLithium batteries?ÿ(with a dedicated charging mode to optimise performance) in addition to standard Lead Acid batteries including AGM, Gel and Wet cell batteries.

Key features:

- Safe?ÿunattended charging:?ÿFeatures inbuilt safety functions (protection?ÿagainst DC short circuit, overheating, overcharging and reverse polarity of the battery), which allow the charger?ÿto be?ÿleft permanently connected to the battery?ÿfor unattended automatic charging.

- Adaptive battery management:?ÿAutomatically adapts and optimises the charging process?ÿrelative to the way in which the battery is being used. This adaptive ability also limits corrosion within the battery by reducing time spent in the absorption stage when possible (eg. when charging a battery which is already nearly fully charged).

- Continued charging during battery use:?ÿOperates even while energy is being drawn from the battery during use.?ÿThe unit will maintain the charge if the battery is already at full capacity.

- Power?ÿsupply function:?ÿCan provide a direct?ÿsupply of power to a 12V load even when no battery is?ÿconnected.

- Dead battery recovery:?ÿThe charger will attempt to recharge a deeply-discharged battery (will start charging?ÿwhen a battery is at 0V) at a low current. As soon as sufficient?ÿbattery voltage is reached, normal charging will resume.

- Silent operation:?ÿThe charger operation is totally silent as there is no cooling fan or any moving parts.

- Storage Mode:?ÿDesigned to prevent aging of the battery when it is not in use. This mode is enabled whenever the battery has not been discharged for 24 hours. Storage mode minimises gassing and corrosion within the battery and prevents other major causes of early battery failure including sulphation.

- Bluetooth connectivity:?ÿEnables the user to remotely program settings (set battery type or charging current),?ÿmonitor data (battery voltage, charge current, and charging cycle status) and download updates for?ÿthe system via any Bluetooth-enabled device, using the free?ÿVictronConnect App.

- Inbuilt temperature sensor:?ÿMeasures the ambient temperature and automatically compensates for temperature when charging lead-acid batteries.

- Charging status LEDs:?ÿ9 LED lights on the front panel indicate the current charging stage (test, bulk, absorption, float, storage) and the charging mode (normal, high, recondition, Lithium).?ÿ

This charger?ÿis fitted with?ÿa?ÿ1.5m mains AC cable with?ÿa UK 3-pin plug.

Specifications:
?ÿ

• Operating Voltage range (AC): 180V - 265V
• DC output current ('normal' mode): 25A
• DC output current ('low' mode): 10A
• DC output voltage: 12V
• Minimum battery capacity ('normal' mode): 83Ah (lead-acid) & 50Ah (lithium)
• Minimum battery capacity ('low' mode): 33Ah (lead-acid) & 20Ah (lithium)
• Absorption charging voltage: 14.2V - 14.7V DC (depending on the battery type)
• Float charging voltage: 13.5V - 13.8V (depending on the battery type)
• Minimum battery voltage: starts charging at 0V ('dead battery')
• Efficiency: 94%
• Standby power consumption: 0.5W
• Operating temperature range: -40?øC?ÿto 50?øC
• Humidity (non condensing): Max 95%
• Temperature compensation (lead-acid only): 16mV/?øC
• Protection: IP65 (splash and dust proof)
• Dimensions: 75 x?ÿ140 x 240 mm
• Weight: 1.9 kg?ÿ

This product is covered by a?ÿ5 year?ÿmanufacturer?ÿwarranty.

The following documents are available to download:

User manual for Victron 25A Blue Smart IP65 Mains Battery Charger (VBC1225WP)

Datasheet for Victron 25A Blue Smart IP65 Mains Battery Charger (VBC1225WP)
