SEAFLO Pressure Pump 23A Series 24V 5.6 lpm/1.5 gpm 40 psi/2.8 bar
DP201504023A
- Dispatched in 2-3 days
- 30 Day Return Policy
Seaflo Water Pressure Pump - 23A Series 24V 1.5 GPH / 5.6 LPH
23A Series Automatic Demand Diaphragm Pump
The water pressure pump - 23A series has: A 2 chamber diaphragm pump, an on-demand long life pressure switch. Is self-priming and capable of being run dry. Compact housing, ignition protected and quiet running with rubber feet for vibration and noise reduction.
- Multiple connector options
- Bypass technology reduces cycling
- Industry standard mount pattern
- Marine grade blocked wiring
- Waterproof grade IP54 with extra cover 60°C (140°F) temperature limit
- Shut-off pressure 35 PSI: 25 PSI±5 PSI (±0.3 bar) Shut-off pressure 40 PSI: 30 PSI±5 PSI (±0.3 bar) Shut-off pressure 70 PSI: 56 PSI±5 PSI (±0.3 bar)
- Valves: EPDM Diaphragm: Santoprene Inlet/Outlet Ports: 5/8" quick connector
- CE, RoHS
- 4 Year Warranty
| Weight | 0.7 kg |
|---|---|
| Brand | Seaflo |
| Voltage | 24V |
| Flow Rate | 1.5 GPH / 5.6 LPH |
| Control Type | Switch & Bypass |
| Wire Connector | 18 AWG x 35 cm |
| Priming Capabilities | 1.5 m / 5' |
| Max Draw | 2.5 A |
| Shut off pressure PSI BAR | 40 / 2.8 |
MORE FEATURES & BENEFITS
• Open flow up to 1.5gpm/5.6lpm
• Dry run capability
• Max Self-priming up to 5 feet/1.5m
• Waterproof grade IP54 with extra cover
• On-demand long life pressure switch
• Configurable reflux function
• Adapt to a variety of scenarios
• Multiple connector options
• By pass technology reduces cycling
• Ignition protected, CE, RoHS
STANDARD PUMP CONFIGURATIONS
|
Model |
Voltage |
Open Flow |
Max Draw |
Shut-off Pressure |
| SFDP1-005-070-23A |
12V
|
0.5/1.9 | 1.8A | 70/4.8 |
| SFDP2-005-070-23A |
24V
|
0.5/1.9 | 1.0A | 70/4.8 |
| SFDP1-007-070-23A |
12V
|
0.7/2.6 | 2.5A | 70/4.8 |
| SFDP2-007-070-23A |
24V
|
0.7/2.6 | 1.2A | 70/4.8 |
| SFDP1-010-040-23A |
12V
|
1.0/3.8 | 3.8A | 40/2.8 |
| SFDP2-010-040-23A |
24V
|
1.0/3.8 | 2.0A | 40/2.8 |
| SFDP1-012-040-23A |
12V
|
1.2/4.3 | 4.2A | 40/2.8 |
| SFDP2-012-040-23A |
24V
|
1.2/4.3 | 2.2A | 40/2.8 |
| SFDP1-015-040-23A |
12V
|
1.5/5.6 | 4.5A | 40/2.8 |
| SFDP2-015-040-23A |
24V
|
1.5/5.6 | 2.5A | 40/2.8 |
